Scan Play (Intro Music Scan)
Press the SCN button 8, then the display
shows “SCN”, then the CD will play the first 10
seconds of each track of the whole disc. Press
the SCN button 8 again to disengage the unit
from scan play.
*
A scan play will start from the track following the one
currently playing.
Repeat Play
Press the RPT button 7, then the display shows
“RPT”, then the track currently playing will be
played repeatedly. Press the RPT button 7
again to disengage the unit from repeat play.
Random Play
Press the RDM button 6, then the display will
show “RDM”, then the entire tracks on the disc
will be played at random. Press the RDM button
6 again to disengage the unit from random play.
14 BD416
English
9. TROUBLESHOOTING
Replace with a fuse of the same amperage. If the
fuse blows again, consult your store of purchase.
Consult your store of purchase.
1. Turn the unit off.
2. Remove all wires attached to the power antenna
lead. Check each wire for a possible short to
ground using an ohm meter.
3. Turn the unit back on.
4. Reconnect each amplifier remote wire to the
power antenna lead one by one. If the amplifiers
turn off before all wires are attached, use an
external relay to provide remote-on voltage
(excessive current required).
Turn off the power, then press the Open button 1
and remove the DCP.
Press the reset button for about 2 seconds with a
thin rod.
Wipe the dirt off with a soft cloth moistened with
cleaning alcohol.
Eject the compact disc before loading the new one.
Clean the compact disc with a soft cloth.
Replace with a compact disc with no scratches.
Let dry for about 1 hour with the power on.
GeneralCD
Problem
Power does not
turn on.
(No sound is
produced.)
No sound output
when operating
the unit with
amplifiers or
power antenna
attached.
Nothing happens
when buttons are
pressed.
Display is not
accurate.
Compact disc
cannot be
loaded.
Sound skips or is
noisy.
Sound is bad
directly after
power is turned
on.
Fuse is blown.
Incorrect wiring.
Power antenna lead is
shorted to ground or
excessive current is required
for remote-on the amplifiers
or power antenna.
The microprocessor has
malfunctioned due to noise,
etc.
DCP or main unit connectors
are dirty.
Another compact disc is
already loaded.
Compact disc is dirty.
Compact disc is heavily
scratched or warped.
Water droplets may form on
the internal lens when the
car is parked in a humid
place.
Cause Measure
Reset button
