This unit is equipped with a number of self-diagnosis functions to protect the system. If a prob-
lem should occur, the user is warned through various error displays. Eliminate the problem
using the procedures shown below.
Problem Cause Measure
Power does not turn on.
(or no sound is produced.)
Fuse is blown.
Replace with a fuse of the same
amperage as the old fuse.
Connections are improper.
Read the attached “Installation/Wire
Connection Guide” once again and
wire properly.
Sound quality is poor.
Playback head is dirty.
Use a cleaning tape, etc. to clean the
head.
No sound while unit can
be operated.
Power ANT lead is shorted
to the ground.
Turn the unit off, first.
Remove all connecting wires from the
power ANT lead, and turn the unit on,
then re-connect a wire one by one to
the power ANT lead.
When sound is muted again, check
the unit with a wire connected last.
8. TROUBLESHOOTING
If a display other than one of the displays above appears, press the reset button. If the problem persists, turn the
power off and contact your store of purchase.
Eject the tape then replace it with a new
one.
Remove the caught or wound tape.
This is a failure of tape mechanism and
consult your store of purchase.
Eliminate the reason for which the tape is
caught.
This is a failure of CD changer’s mecha-
nism and consult your store of purchase.
Replace with a non-scratched, non-warped
disc.
Eject the disc then reload it properly.
TapeCD changer
Error Display Cause
Tape cannot be played due to defective
tape such as cut tape.
Tape is caught and cannot be played.
Tape mode cannot be detected.
Tape is caught and cannot be ejected.
A CD inside the CD changer is not
loaded.
A CD inside the CD changer cannot be
played due to scratches, etc.
A CD inside the CD changer cannot be
played because it is loaded upside-down.
TAPE ER1
TAPE ER2
TAPE ER4
TAPE ER8
CDCH ER2
CDCH ER3
CDCH ER6
Measure
