DSP Operations
Inputting a title
You can give a title to the user memory of the
DSP, G.EQ, S.EQ and P.EQ that you have ad-
justed yourself.
1. Press A-M button # to select the adjustment
mode in which you want to give a title.
2. Press BND button @ to select “USER”.
“USER” appears in the function mode indica-
tion @.
3. Press one of the Preset buttons 9 to select
the user memory to which you want to give a
title.
4. Press TITLE button 4.
5. Press the right or left side of SEARCH button
$ to move the cursor.
6. Press DISP button 0 to select a character.
There are capital letters, small letters, num-
bers, symbols and umlaut available for the
character.
7. Turn the Rotary knob % clockwise or coun-
terclockwise to select the character you want
to input.
8. Repeat steps 5 to 7 to input the title.
9. Press and hold ENT button 2 for 2 seconds
or longer to put the title into memory. The title
input mode is canceled.
Easy mode/G.EQ operations
Note:
• The adjustment made in easy mode is not reflected
in the adjustment in professional mode. On the
contrary, the adjustment made in professional
mode is not reflected in the adjustment in easy
mode.
G.EQ effect on/off
While the “G.EQ” indication 4 is lit in the dis-
play, the G.EQ effect is set to “ON”.
∗ The factory default setting is “ON”.
1 Press A-M button # and select “G.EQ”. While
“G.EQ” is selected, “G.EQ” blinks in the dis-
play.
2. Press DISP button 0.
3. Press A-M button #. “G.EQ” in the display is
changed from blinking to lit or unlit.
∗ When “G.EQ” is unlit, the G.EQ effect is set to
OFF.
Note:
• If the G.EQ effect is set to OFF, the adjustment
made in the “G.EQ operations” is not reflected in
the music source.
Selecting a G.EQ menu
1. Press A-M button # and select “G.EQ”.
“G.EQ” blinks in the display.
2. Press BND button @ to select “BASC” (ba-
sic). “BASC” appears in the function mode
indication @.
3. Press one of the Direct buttons 9 and select
the desired G.EQ menu.
∗ To select the user memory, press BND button
@ to select “USER” and press one of the Di-
rect buttons 9.
Editing/storing a G.EQ menu (User
memory)
1. Select a G.EQ menu which you want to edit
on the basis of.
2. Press and hold ADJ button 4 for 1 second or
longer.
3. Press the right or left side of SEARCH button
$ to select the frequency to be adjusted.
There are 50Hz, 100Hz, 200Hz, 400Hz, 1kHz,
3kHz and 12kHz available for the adjustment
frequency.
∗ For details on each adjustment item, refer to the
owner’s manual supplied with the DPH7500z.
4. Turn the Rotary knob % clockwise or coun-
terclockwise to make the adjustment. The
adjustment range is from –12dB to +12dB.
5. Repeat steps 3 to 4 to complete the adjust-
ment and press ADJ button 4.
6. Press and hold one of the Direct buttons 9
for 2 seconds or longer to store the edited
contents.
∗ You can give a title to the user memory. For
the inputting method of titles, refer to the sub-
section “Inputting a title” in the “Operations
common to each mode”.
Easy mode/DSP operations
DSP effect on/off
When the “DSP” indication 5 is lit in the display,
the DSP effect is set to “ON”.
∗ The factory default setting is “ON”.
1. Press A-M button # and select “DSP”. While
“DSP” is selected, “DSP” blinks in the display.
