-11-
Jump Button – This button allows the user to jump to the
Previous Channel (i.e., switch between the current and previ-
ous channel.
Preset/Direct Button (pre./dir.) - Each momentary press of
the PRESET button allows the user to switch between (3) banks
of Channel presets (10 presets each A, B, and C) plus Direct
channel entry. When in any of the three preset banks, momen-
tarily pressing any of the number buttons will recall the stored
channel. In the Direct (Dir) mode, use the number buttons to
directly enter the desired channel number followed by pressing
the Rotary/ Select Knob.
Keypad Buttons 0-9 - These buttons are used to directly enter
a desired channel number. They are also used when entering
and recalling preset channel numbers into memory.
Display Screen Features - Shown to the right is an example
of an active Display Screen (see Figure 3). Pressing the DIS-
PLAY button from the Default display switches between the
artist name/song title screen, artist name/song title with stock
screen, artist name/song title with sports screen, or large letter
format. When the letter size changes, the field will scroll. This
feature is useful when viewing the display at a distance.
Signal
Strength
Channel
Number
Artist
Channel
Name
Momentary Preset Indicator
(Stays on for 2-seconds)
Time
Song
Title
Stock, Sports,
and More Info
Figure 3. Xpress Receiver Unit Display Screen
