Audiolab 8000P Stereo Amplifier User Manual



a u d i o l a b
International Audio Group
IAG house,
Sovereign Court,
Ermine Business Park
Huntingdon, PE29 6XU
S p e c i f i c a t i o n
8 0 0 0 P
Power Amplifier
Rated output power
Typical output power
Input for full rated power
Input impedance
Gain
Signal to noise
Frequency response (-3 dB)
Frequency response (±0.3dB)
Total harmonic distortion + noise
Dimensions (WxHxD - mm)
100 W per channel into rated load impedance (8), 150 W into 4
120 W per channel into rated load impedance (8), 180 W into 4
1.0 V rms
47 k nominal
29.0 dB at 1 kHz
Greater than 95 dB (relative to 0 dBW)
0.1 Hz - 75 kHz
20 Hz - 20 kHz
Less than 0.05%
445 x 74 x 337
The 8000P is a classic two-channel power
a m p l i f i e r, delivering over 100W per
channel and a peak output of over 40
Amps.
Comfortably able to drive most
loudspeaker loads, the 8000P is equally
useful in Home Cinema configurations
as it is in high performance stereo
applications.
A simple aesthetic and wide compatibility
with other components ensures the 8000P
amplifier is an ideal building block for
your current and future systems.
All Audiolab 8000 series power amplifiers
are gain-matched for easy integration into
a growing system.
