System Specifications
Frequency Response: 32 Hz – 18 kHz (-10 dB)
Maximum Output: 101 dB SPL (1m)
System Power: 58 watts RMS @ 1% THD
Satellite Power: 7 watts RMS @ 1% THD
Subwoofer Power: 44 watts RMS @ 1% THD
System THD (Input to Amplifier Output): <0.6% THD @ 1 kHz
Signal-to-Noise Ratio: > 78 dB
Channel Separation: > 55 dB
Input Impedance: 10 k ohm
Input Sensitivity: -11.76 dBu (200 mV RMS)
Maximum Input Level: +12 dBu (3.08 V RMS)
Volume Control: 70 dB attenuation maximum
Treble Level Control: +/- 9 dB @ 10 kHz
Bass (Subwoofer) Level Control: +/- 10 dB @ 100 Hz
Recommended Headphone Load Impedance: 32 ohms, each channel
Headphone Output: 7mW into 32 ohms, both channels driven
Drivers (per satellite): Six 1” / 25 mm full-range 8 ohm micro drivers
Subwoofer Driver: One 6.5” / 165 mm long-throw 4 ohm woofer
Cables (Supplied with SLS6221) • Satellite: 4-pin DIN cable (3 m / 9.8 ft.) with extension (2 m / 6.6 ft.)
• Controller: 9-pin DIN cable (3 m / 9.8 ft.)
• RCA input cable (5 m / 16.3 ft.)
AC Power Requirements: • 120 V AC @ 60 Hz (USA, Canada and applicable Latin American and Asian countries).
• International versions with 220 V & 230 V power supplies are available.
Input Connections: • Stereo RCA inputs Red (right) and White (left) on rear panel of subwoofer.
• One 3.5 mm stereo input on rear panel of subwoofer.
• One 3.5 mm auxiliary input is located on the wired control pod.
Controls: • Wired Control Pod: Rotary Up/Down Volume, Bass, Treble, and On/Standby
• Infrared Wireless Remote: Up/Down Volume, Bass, Treble, and On/Standby
Enclosure Material & Finish: • Satellites: Black injection-molded plastic with painted metal grill
• Subwoofer: Black painted 9 mm MDF with injection-molded front panel
and painted metal grill
Satellite Dimensions: • 2.5" (W) x 1" (D) x 14.4" (H)
• 64 mm (W) x 26 mm (D) x 365 mm (H)
Subwoofer Dimensions: • 8.5" (W) x 7.9" (D) x 16" (H)
• 216 mm (W) x 198 mm (D) x 406 mm (H)
Weight: • Shipping: 22.5 lbs (10.2 kg)
• Net weight of satellites, subwoofer and control pod: 19 lbs (8.6 kg)
Visual communication is a powerful thing, but nothing adds to the overall impact like
high-fidelity audio. Flat panel displays (FPDs) are the video communication media of choice
for corporate, institutional, retail, and commercial clients – anyone who wants to present
high-impact, high-resolution visual information.
Unfortunately, choices for FPD audio playback have been limited to low-performance,
poor-quality speaker systems. Until now.
Introducing the Altec Lansing SLS6221 system. The first professional-quality 2.1 powered
audio system specifically designed for use with FPDs. Now you can provide your clients
with high-fidelity, high-definition audio to match the quality of their video presentations.
© 2004 Altec Lansing Professional. All rights reserved.
1000 W. Wilshire Blvd., Suite 362, Oklahoma City, OK 73116
Tel. 405-848-3108 / Fax. 405-848-3216 / proinfo@alteclansing.com
Visit www.altecpro.com
PROFESSIONAl
Introducing a Sound Solution
for All Flat Panel Displays
SLS6221
Proudly distributed by
in the United States www.electrograph.com 1-800-776-5768
PROFESSIONAl
RIGHT LEFT CONTROLLER INPUT R L
AUDIO INPUT
